Features
- Easy to operate
- Stable performance
- Efficient splicing process
Technical Specifications
| Optical fiber cladding diameter | 125 μm to 550 μm |
| Optical fiber coating diameter | 250 μm to 1000 μm |
| Optical fiber quantity | Single optical fiber |
| Cleaving length | 3 mm to 15 mm,
typical 5 mm; measured with the coating layer clamped. |
| Typical fusion splicing loss | PMF: 0.05 dB
NZDSF or LDF: 0.05 dB MMF: 0.02 dB |
| Typical fusion splicing time | PMF (PANDA): 30 seconds
NZDSF or LDF or MMF: 25 seconds |
| Typical extinction ratio | -40 dB |
| Electrode life | 2,500 arc discharges, typical, corresponds to optical fiber fusion splicing |
| Tension test | 0.44 lbf to 0.55 lbf (1.96 N to 2.45 N) |
| Amplified factor | 50 to 300, variable |
| Automatically splicing | Supply |
| Splicing mode | Automatic, manual |
| Number of splicing data storage | 10,000 for splicing data |
| Operating condition | Humidity 0 to 95%; temperature 32 °F to 104 °F (0 ℃ to 40 ℃), non-dew |
| Storage condition | Humidity 0 to 95%; temperature to 40 °F to 176 °F (to 40 ℃ to 80 ℃), non-dew |
| Dimensions | 14.17 in x 9.37 in x 8.27 in (360 mm x 238 mm x 210 mm) |
