Features
- Measures exhaust gases from gasoline engine vehicles
- Uses NDIR technology for hydrocarbon, carbon monoxide, and carbon dioxide detection
- Uses electrochemical sensors for oxygen and nitrogen oxide detection
- LCD screen display for convenient setup and operation
- Automatically calculates and displays extra air coefficient
- Detects emissions for CNG, LPG, and ethanol gasoline engines
- Compact, lightweight, and easy to move
- Equipped with induction motor speed measuring pliers
- Supports license plate number input function
- Optional micro thermal printer for instant reports
- Optional engine oil temperature measuring probe
- Optional speed measurement adapter models available
- Optional car power inverter for versatile use
Technical Specifications
| Communication Interface | RS-232C digital serial communication |
| Data Storage | Stores and retrieves up to 200 sets of data |
| Standards Compliance | Meets GB 18285-2005 accuracy requirements Complies with ISO 3930 or R99 I OIML standards |
| Effective length of Optimal Channel | 8.46 in (21.5 cm) |
| Equivalent Length of Optimal Channel | 16.93 in (43 cm) |
| Working Power Supply | AC 220V ±22V, 50Hz ±1Hz |
| Power Consumption | 150W |
| Pressure | 80.08 kPa to 106.0 kPa |
| Opacity Range | 0% to 98.6% |
| Light Absorption Coefficient Range | 0 m⁻¹ to 16.08 m⁻¹ |
| Speed Range | 300 rpm to 6000 rpm |
| Oil Temperature Range | 32 °F to 392 °F (0 °C to 200 °C) |
| Flue Gas Temperature Range | 32 °F to 302 °F (0 °C to 150 °C) |
| Oil Temperature Accuracy | ±9 °F (±5 °C) |
| Flue Gas Temperature Accuracy | ±9 °F (±5 °C) |
| Opacity Resolution | 0.01% |
| Light Absorption Coefficient Resolution | 0.01 m⁻¹ |
| Speed Resolution | 1 rpm |
| Temperature Resolution | 1 °F (1 °C) |
| Opacity Accuracy | ±2.0% |
| Speed Accuracy | ±50 rpm |
| Effective Optical Path Length | 8.46 in (21.5 cm) |
| Equivalent Optical Path Length | 16.93 in (43 cm) |
| Operating Pressure Range | 11.61 psi to 15.38 psi (80.0 kPa to 106.0 kPa) |
| Operating Temperature Range | 32 °F to 104 °F (0 °C to 40 °C) |
| Operating Humidity Range | ≤95% RH |
| Power Supply | AC 220 V ±10%, 50 Hz ±1 Hz |
| Power Consumption | 150 W |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Humidity | <95% |
| Dimensions | 10.24 in × 7.09 in × 17.72 in (26.0 cm × 18.0 cm × 45.0 cm) |
| Weight | 13.2 lb (6 kg) |
