Technical Specification
| Test Signal Frequency | 10 Hz to 10 kHz, adjustable |
| Electrical Level | 0.1 V to 2 V Adjustable |
| Bias Voltage | 0 mV to 1500 mV |
| Test Parameters | L/C/R/Z X/D/Q/θ/ESR |
| DCR Range | 0.0001 Ω to 99.99 MΩ |
| LCR Parameters Range | R 0.0001 Ω to 99.99 MΩC 0.01 pF to 99.999 uF
L 0.01 uH to 9999 H |
| Screen | 3.5″ TFT, 5 digits |
| Measurement Time (≥ 10 kHz) | Fast :8 meas/s, Medium:4 meas/s, Slow: 2meas/s |
| Equivalent Circuit | Serial or Parallel |
| Backlight Adjustable | yes |
| Components Auto identification | Yes |
| Operation Way | Auto or Manul range |
| Language | English or Chinese |
| Correction | Open or Short |
| Filter | -50 % to 5 + 50 % (Fix point 1 %, 5 %, 10 % 20 %) |
| Comparator | 3 Levels for PASS 1 Level for FAIL 1 Level for AUX |
| Max/Min/Ave. | yes |
| SCPI | Support |
| Interface | USB, RS232 (or 485), Handle or (GPIB USB HOST Available) |
| Power Supply | AC 110 V to 220 V,45 Hz to 65 Hz |
| Product Size | 10.43 in x 12 in x 4.13 (265 mm x 305 mm x 105 mm) |
| Product Weight | 5.7 lb (2.3 kg) |
