Features
- High performance built-in amplifier
- All round LED indicator
- Soft flexible cable
- Designed with red sleeve tail to protect the wiring interface
Technical Specifications
| Material | ABS |
| Detection Distances | 0.39 in (10 mm) |
| Standard Sensing Object | Non-Metal |
| Response Frequency | 200 Hz |
| Hysteresis | Less than 10% of sensing distance |
| Detection Method | NPN NO |
| Operating Voltage | DC 12 V to 24 V |
| Current Consumption | Less than 10 mA (No Load) |
| Load Current | 100 mA Max at 24 VDC |
| Residual Voltage | Less than 1 VDC |
| Leakage Current | Less than 0.01 mA (No Load) |
| Protection Degree | IP66 |
| Operating Temperature | -13 °F to 158 °F (-25 ℃ to 70 ℃) |
| Reverse Polarity Protection | Yes |
| Short Circuit Protection | Yes |
| Wire Method | Diameter 0.16 in x 6.56 ft (4 mm x 2 m) with 3 wires, 4 wires, 2 wires configurations |
