Features
- Fast Splicing
- Fast heating
- 5000 times electrode service life
- Average splice loss 0.01 dB
- Can store 10000 sets of splicing results and 2000 sets of images
- Real time discharge correction
- USB interface
- Small size, easy to carry
Technical Specifications
| Type | Fiber fusion splicer |
| Cladding Diameter | 80 μm to 150 μm |
| Cutting Diameter | 8 mm to 16 mm |
| Return Loss | >> 60 dB |
| Heating Time | 6 s |
| Battery | 7800 mAh |
| Electrode Life | 5000 discharges |
| Data Storage | 10000 sets |
| Tensile Test | 1.96 N to 2.25 N |
| Altitude | 0 mm to 5000 mm |
| Humidity | 0 % to 95 % |
| Wind Speed | 15 m per s |
| Magnification | 320 times |
| Power | AC 100 V to 240 V, DC 9 V to 14 V |
| Temperature | -4 ℉ to 122 ℉ (-20 ℃ to 50 ℃) |
