Technical Specifications
| Resolution | 0.1% Freq |
| Waveform Amplitude | ±3.5 V max |
| Output Impedance | 50 Ω |
| Output Current | 50 mA lpeak |
| Number of Channels | 1 |
| DAC Clock | 2 K to 200 MHz adjustable |
| Wavelength | 4 KSa |
| Vertical Resolution | 12 bits |
| Waveform Stability | <30 ppm |
| Bandwidth | 25 M |
| Output Frequency | DC 1 Hz to 25 MHz (sine wave up to 75 MHz) |
| Harmonic Distortion | -50 dBc (1 KHz) ，-40 dBc (10 KHz) |
| Low Pass Filter | no |
| Frequency Range | DC-50 MHz |
| Input Signal Amplitude | 400 Vpp to 18 Vpp |
| Coupling Method | DC |
| Frequency Measurement Accuracy | ±Time Base Error ±1 Count |
| Input Resistance | >100 K Ω |
| Number of Digits | 12 digital outputs and 6 digital inputs |
| Level | LVCMOS |
| Temperature | 32 °F to 158 °F (0 ℃ to 70 ℃) |
| Humidity | ＜95% |
| Accessories | 1 BNC cable, 1 double-headed USB |
| Size | 7.28346 in × 5.90551 in × 1.06299 in (185 mm × 150 mm × 27 mm) |
| Weight | 1.10231 lb (500 g) |
