Features
- 15 S Fast heating
- 6 s fast splicing
- 5 in (12.7 cm) display simultaneously align fibers loss display
- Automatic Heating
- Disassembly of three in fibre holder
- Six motors core alignment
Technical Specifications
| Fiber Alignment | Core or cladding or manual alignment |
| Splicing Time | 6 s |
| Heating time | 15 s |
| Heating mode | Automatic heating |
| Focus mode | Six motors auto focus |
| Splice Loss | 0.025 dB (SM), 0.01 dB (MM), 0.04 dB (DS or NZDS) |
| Control Technology | Real Time Control And calibration of fusion ARC |
| Return Loss | Better than 60 dB |
| Fiber Diameter | 80 µm to 150 µm, 100 µm to 1000 µm |
| Tension Test | 2 N |
| Splicing Mode | Normal or High Precision Splicing |
| Power Supply | Input AC 100 V to 240 V 50 Hz or 60 Hz, Output DC 13.5 V or 4.8 A |
| Temperature | 5 °F to 122 °F (-15 °C to 50 °C) |
| Humidity | < 95 % RH |
| Wind speed | ≤ 15 m/s |
