Features
- Measuring frequency up to 100 KHz, continuous adjustable frequency of 1 Hz step by step
- Test level 10 mv to 2000 mv, 1 Hz continuous adjustable
- Support dc resistance (DCR), electrolytic capacitor measurement
- The internal bias voltage output 0 mv to 1500 mv
- 5″ TFT display, five shows
- Communications: USB Device, RS232, Handle
- Data record function (maximum, minimum, average)
- Support SCPI communication protocol
- Provide the system Settings, can according to need to configure the Chinese or English, buzzer, screen brightness, etc.
- Basic measurement accuracy of 0.1 %
- Manual and automatic range
- With open circuit and short circuit calibration function
- Comparator separation (5), alarm function
Technical Specifications
| Warranty | 1 Year |
| Weight | 13.22 lb (6 kg) |
| Power Voltage | 220 V.AC / 50Hz ± 10 %, OR 110 V.AC / 50 Hz ± 10 % |
| Power Consumption | < 10 W |
| Display | 3.5″ TFT LCD, resolution 480 x 320 |
| Interfaces | standard: RS232, USB Device, Handler |
| Service Environment | 32 °F to 104 °F (0 ℃ to 40 °F) |
| Sizes | 10.43 in x 4.13 in x 12.01 in (265 mm x 105 mm x 305 mm) |
| Measuring Frequency | up to 100 KHz |
| Test level | 10 mV to 2000 mV, 1 Hz continuous adjustable |
