Features
- 4CH oscilloscope + EXT + AFG + DVM
- Auto range function
- 80 MHz to 250 MHz bandwidth
- Minimum range 500 μV or div,1 GS/s sample rate
- Over 32 types of auto measurement function
- Advanced digital trigger system
- High trigger sensitivity
- Over 14 types of trigger function
- Edge, overtime, pulse, pattern, interval, etc.
- Serial bus triggering and decode
- Bus protocol information
- Quickly and intuitively displayed in table form
- Function arbitrary signal generator25 MHz,12 Bits
- Resolution, 200 MHz DDS, ARB
- Square wave or sine wave or triangular wave
- Trapezoidal wave impulse wave DC etc.
- Easy to simulate the sensor
- Integrated USB Host or Device
- Convenient to communicate with PC
- Support U stick storage or system update
- Support a variety of SCPI remote control command
- Support optional RS 232 port, LAN port (Optional)
- Stable and reliable quality, sturdy and durable
Technical Specifications
| Bandwidth | 250 MHz,200 MHz,100 MHz,80 MHz |
| Sample Rate Range | 1 GS/s |
| Waveform Interpolation | (sin x) or x |
| Record Length | Maximum 64 K samples per single channel;
Maximum 32 K samples per dual channel (4 K, 32 K optional) |
| SEC Or DIV Range | 2 ns or div or 100 s or div
1, 2, 5 sequence |
| Sample Rate And
Delay Time Accuracy |
±50 ppm |
| Delta Time Measurement Accuracy
(Full Bandwidth) |
Single shot, Normal mode
± (1 sample interval +100 ppm × reading + 0.6 ns) >16 averages ± (1 sample interval + 100 ppm × reading + 0.4 ns) Sample interval = s or div ÷ 200 |
| Vertical | |
| Ad Converter | 8-bit resolution, each channel sampled simultaneously |
| VOLTS or DIV Range | 500 μV or div to 10 V or div at input BNC |
| Position Range | 500 μV or div to 20 mV or div, ±400 mV
50 mV or div to 200 mV or div, ±2V 500 mV or div to 2 V or div, ±40 V 5V or div to 10 V or div, ±50 V |
| Dimension | 15.75 in x 11.02 in x 9.05 in (40 cm x 28 cm x 23 cm) |
| Weight | 9.92 lb (4.5 kg) |
