Features
- Designing, testing, troubleshooting, and repairing
- Electronic and electroacoustic devices
- Circuit and equipment
- Testing in cellular and wireless systems
- Broadcasting, television and radio systems
- Semiconductor component testing etc
- 1 μHz full band resolution 2. 5 MHz to 30 MHz pulse waveform
- Adjustable rise or fall time
- 14 bit or 16-bit vertical resolution
- Two equivalent performance channels
- Max arbitrary waveform length of 8 k or 16 M points; 48 or 161
- Nonvolatile waveforms storage
Technical Specifications
| Max Frequency | 25 MHz |
| Channels | 2 |
| Sampling Rate | 125 M/s |
| Waveforms | Sine, square, ramp, pulse, noise, DC, arbitrary; UTG2000B only: harmonic |
| Working Modes | Output on or off, continuous, modulation, sweep, burst |
| Modulations | AM, FM, PM, ASK, FSK, PSK, PWM; UTG2000B only: BPSK, QPSK, OSK, DSB-AM, SUM, QAM |
| Length | 8 pts to 8 kpts |
| Vertical Resolution | 14 bits |
| Sine | 1 μHz to 25 MHz |
| Square | 1 μHz to 5 MHz |
| Pulse | 1 μHz to 5 MHz |
| Ramp | 1 μHz to 400 kHz |
| Arbitrary | 1 μHz to 5 MHz |
| Noise | 25 MHz (-3 dB) |
| Resolution | 1 μHz |
| Accuracy | ±0.5 ppm 77 °F (25 ℃)
First year aging rate: 1 ppm Temperature coefficient: ±0.5 ppm or ℃ |
| Temperature Coefficient | ＜2ppm or ℃ |
| Interfaces | USB Host, USB Device, frequency counter |
| Power | 100 V to 240 V AC rms, 50 Hz or 60 Hz |
| Display | 4.3 in (10.9 cm) TFT LCD, WVGA (480 x 272) |
| Product Color | White and grey |
| Size | 10.4 in x 4.33 in x 12.5 in (265 mm x 110 mm x 320 mm) |
| Weight | 7.05 lb (3.2 kg) |
