Features
- Core alignment
- 7 second rapid fusion
- 18 s to 26 s rapid heating
- 5 in (12.7 cm) high resolution screen
- Stable welding effect
- 3 in 1 universal fixture
- Bare fiber
- Jumper pigtail
- Leather cable
- 7800 MAH large capacity Lithium battery
- 400 times focus zoom
- Reservable content
- USB data input and export
- Nonslip bottom pad
Technical Specification
| Applicable | SM (G.652 & G.657), MM (G.651), DS (G.653), NZDS (G.655) |
| optical fiber and self-defined and optical fiber types | Splicing loss 0. 02 dB (SM), 0. 01 dB (MM) 0. 04 dB (DS or NZDS) |
| Return loss | Over 60 dB |
| Typical splicing duration | 9 s |
| Typical heating duration | 26 s (configurable heating time and adjustable heating temperature) |
| Optical fiber alignment | Precise alignment, fiber core alignment, cladding alignment |
| Optical fiber diameter | Cladding diameter: 80 μm to 150 μm Coating layer diameter: 100 μm to 1000 μm |
| Cutting length | Coating layer below 250 μm: 0.315 in (8 mm) to 0.63 in (16 mm) Coating layer 250 μm -1000 μm: 0.63 in (16 mm) |
| Tension test | Standard 2 N (optional) |
| Working Temperature | 14 °F to 122 °F (- 10 °C to +50 °C) Humidity: <95% RH (no condensation) |
| Splicing loss storage | 5000 latest splicing results are stored in the built-in storage. |
| Built-in battery | Supports continuous splicing and heating for not less than 200 times |
| Power Supply | The built-in lithium battery 11.8 V supplies the power, charging time ≤3.5 hrs |
| Power saving | 15% of the power of the lithium battery can be saved in a typical environment. |
| Weight | 3.9 lb. (1.77 kg): excl. battery 4.72 lb. (2.14 kg): incl. battery |
