Technical Specifications
| Splice Method | Active clad alignment |
| SM Quick Mode | 8 s |
| SM Average | 10 s |
| Heating Time | Quick mode 18 s |
| Focus Mode | 4 motors auto focus |
| Applicable Fibers | SM, MM, DS, NZDS |
| Splice Loss | 0.025 dB (SM), 0.01 dB (MM), 0.04 dB (DS or NZDS) |
| Control Technology | Real-time control and calibration of fusion ARC |
| Return Loss | Better than 60 dB |
| Fiber Diameter | Cladding diameter: 0.003 in to 0.005 in (80 μm to 150 μm) Coating Diameter: 0.003 in to 0.03 in (100 μm to 1000 μm) |
| Software Upgrade | Mobile APP update, turn on Blue-tooth sync to the machine |
| Lighting | External |
| Fiber Holders | 3 in 1 fiber holder, SM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable |
| Magnification | 300 for X or Y view, 150 for X or Y view |
| Screen | 5 in (12.7 cm) TFT color display |
| Splicing Mode | Normal or high precision splicing |
| Splicing Method | Fully automatic, step by step splicing |
| Splicing Record Storage | Synchronize to the phone, the server to cloud storage unlimited |
| Built-in Battery | 7800 mA high-capacity lithium battery, charging time less than 3.5 hours, continuous splicing and heating about 260 times |
| Power Supply | Input AC 100 V to 240 V 50 Hz or 60 Hz, output DC 13.5 V or 4.8 A, the current power mode can be identified, real-time detection of battery power |
| Operating Conditions | Temperature: -5 °F to 122 °F (-15 ℃ to 50 ℃),
Humidity: less than 95 % RH (no condensation) Working altitude: 0 ft to 3.1 mi (0 m to 5000 m). Resist max. wind speed: less than 15 m/s |
| Shrinkable Tube | 1.57 in, 2.36 in (60 mm, 40 mm) |
| Optical Power Meter | Wavelength: 850 nm, 1300 nm, 1310 nm, 1490 nm, 1550 nm, 1625 nm Measuring Range: -70 dB to 6 dB Absolute Error: less than 0.3 dB (-50 dbm to 3 dbm range) |
