Features
- HC1 is the most compact model of all our MPG series
- Developed for usage in numerous industrial areas
- Compact, thin-line and lightweight (26mm)
- Multiplication selection can be set according to customers’ requirement
- Sealed structured box
- RoHS compliant (box or cord)
- Exclusive easy to attach holder as a standard accessory
- Rubber magnet for option
Technical Specifications
| Operating temperature | 14 °F to 140 °F (-10 ℃ to +60 ℃) |
| Storage temperature | -40 °F to 158 °F (-40 ℃ to +70 ℃) |
| LED Lamp | DC 24 V green Led |
| Optional axis | 4 (2 or 3 or 4 or 5 or 6 Axes Optional) |
| voltage | 5 V or 12 V or 24 V |
| Resolution | 25 ppr or 100 ppr |
| IP | IP67 |
| Immunity to interference | EN50082-2 Standard |
| Other specifications | pulse can custom logo |
| Crimped cable | 9.84 ft or 16.40 ft (3 m or 5 m) |
| Straight cable | Customizable length |
| LED Visible Indicator | DC 24 V Green |
| Size | 4.88 in × 2.87 in × 1.02 in (124 mm × 73 mm × 26 mm) |
| Weight | 0.001 lb (750 g) |
