Technical Specifications
| Parameters | Cs – Rs, Cs – D, Cp – Rp, Cp – D, Lp – Rp, Lp – Q, Ls – Rs, Ls – Q, Rs – Q, R – X, Z – θ rad, Z – θ deg |
| Monitoring Parameters | Z, D, Q, θr, θd, R, X, G, B, Y, Vac, Iac, Δ, Δ% |
| Accuracy | 0.05 % ± 5 dgt |
| Frequency | 10 Hz to 300 kHz (continuous frequency, frequency resolution 0.00 1 Hz |
| Display Range | L: 0.00001 μH to 999999 H C: 0.00001 pF to 999999 μF R, Z: 0.00001 Ω to 99.9999 MΩ D: 0.00001 to 9.99999 Q: 0.00001 to 99999.9 Δ%: -999999 % to 999999 % θdeg: -179.999° to 179.999° θrad: -3.14159 to 3.14159 |
| Source Resistance | 30, 50 and 100 Ω |
| Range | Automatic, manual and nominal 9 ranges |
| Display Max | 6 digital, principle parameter: 999999 Sub parameter: 999999 Monitor parameter: 999999 |
| Signal Level | 0.01 V to 2.00 V (10 mV steps) |
| Speed | 30 t/s, 10 t/s, 6 t/s, 3 t/s 1 to 256 average is available |
| Comparator | 14 – bin sorting, 10 – bin GD, 1 – bin NG, 1 – bin AUX, 2 – bin principle parameters NG; count function: MAX – 999999 |
| Voltage | 90V AC to 250V AC |
| Size | 10.39 in x 4.21 in x 13.78 in (264 mm x 107 mm x 350 mm) |
| Weight | 8.82 lb (4 kg) |
| Max Power | 20 VA |
| Frequency | 50 Hz to 60 Hz |
