Features
- Low Insertion Loss
- High Extinction Ratio
- High Isolation
- High stability and reliability
Technical Specification
| Wavelength | 1310 nm to 1550 nm |
| Operating Bandwidth | ±40 nm |
| Excess Loss | ≤0.7 dB |
| Uniformity | ≥0.4 dB |
| Extinction Ratio | ≥26 dB |
| Return loss | ≥50 dB |
| Power handling | 2.5 W |
| Fiber Type | SMF -28 or HI 1060 |
| Storage temperature | -40 °F to 80 °F (-65 °C to 115 °C) |
| Dimensions | 0.21 in x 1.37 in (5.5 mm × 35 mm) |
