Features
- 100 MHz, 200 MHz, 350 MHz models
- Upgradable to 500 MHz
- Real-time sampling rate up to 2 GSa/s
- Up to 500,000 wfm/s (Sequence mode)
- Display of 1 in (25.4 cm) with 1024 x 600 resolution
- Touch Screen: Capacitive, supports multi-touch gestures
- Built-in web server enables remote control via LAN port using a web browser
- External mouse and keyboard support for enhanced usability
- 10-bit for higher resolution and reduced noise
- ideal for detailed waveform analysis
- Vertical and horizontal zoom features for precise examination
- Higher sensitivity and accuracy for detailed analysis loop testing
- Intuitive UI with list and cursor measurements for ease of operation
Technical Specification
| Models | 100 MHz, 200 MHz, 350 MHz (Upgradable to 500 MHz) |
| Sampling Rate | Real-time sampling rate up to 2 GSa/s |
| Waveform Capture Rate | Up to 500,000 wfm/s (Sequence mode) |
| Display | 10.1 in (25.4 cm) with 1024 pixels x 600 pixels resolution |
| Touch Screen | Capacitive, supports multi-touch gestures |
| Remote Control | Built-in web server enables remote control via LAN port using a web browser |
| Usability | External mouse and keyboard support for enhanced usability |
| Resolution and Noise | 10-bit for higher resolution and reduced noise, ideal for detailed waveform analysis |
| Zoom Functionality | Vertical and horizontal zoom features for precise examination |
| Sensitivity and Accuracy | Higher sensitivity and accuracy for detailed analysis |
| Loop Testing | Capability for power control loop testing |
| User Interface | Intuitive UI with list and cursor measurements for ease of operation |
