Features
- 200 MHz or 100 MHz or 60 MHz bandwidth
- 1 GSa/s Real Time sample rate
- Large 7 in (17.78 cm) color display,WVGA 31.5 in x 18.9 in (800 mm x 480 mm)
- Record length up to 1 M, VGA
- Trigger mode edge or pulse width/line selectable video/slop/overtime etc
- USB host and device connectivity, standard
- Multiple automatic measurements
- Four math functions, including FFTs standard
Technical Specification
| Voltage | AC 100 V to 240 V |
| Plug type (Optional) | EU plug, US plug |
| Sample Rate | Real-Time Sample: 1 GS/s |
| Normal | Normal data only |
| Peak Detect | High-frequency and random glitch capture |
| Average | Waveform Average, selectable 4 , 8 , 16 , 32 , 64 , 128 |
| Inputs Coupling | AC, DC, GND |
| Inputs Impedance | 1 MΩ ±2% II 20 pF ±3 pF |
| Probe Attenuation | 1 X, 10 X |
| Supported Probe Attenuation Factor | 1 X, 10 X, 100 X, 1000 X |
