Features
- Compatible IEEE 802.3 ah 1000 BASE – PX20/ PX20+ GEPON application
- Applied to EPON OLT for a Single Fiber Bi-directional EPON System
- SFP, Single SC connector, Digital Diagnostic Interface Compliant with SFF – 8472
- Burst Digital Receiving Signal Strength Indication
- Single 3.3 V power supply
- Operation case temperature -40 ºF to 185 ºF (-40 ºC to 85 °C) for industrial,
- -13 ºF to 185 ºF (-25 ºC to 85 ºC) for extended and
- 14 ºF to 185 ºF (-10 ºC to 70 ºC) for commercial
Technical Specifications
| R Wavelength | 1310 nm |
| T Wavelength | 1490 nm |
| Distance | 20 km |
| Optical Power | 3 dBm to 7 dBm |
| Receiver Damaged Threshold | 0 dBm |
| Power Supply | 4.2 V |
| Date Rate | 1.25 Gb/ s |
| Operating Humidity | 5% to 95 % |
| Temperature | -40 ºF to 185 ºF (-40 ºC to 85 ºC)
-13 ºF to 185 ºF (-25 ºC to 85 ºC) 14 ºF to 185 ºF (-10 ºC to 70 ºC) |
