Features
- Supports up to 10.7 Gbps bit rates
- Hot-pluggable SFP+ footprint
- 1270 nm DFB laser and APD photodiode
- Up to 37.21 mi (60 km) for SMF transmission
- Compliant with SFP+ MSA and SFF-8472 with single LC receptacle
- Compatible with RoHS
- Real Time Digital Diagnostic Monitoring
Technical Specifications
| Wavelength | TX: 1270 nm or RX: 1330 nm |
| Max Distance | 37.28 mi (60 km) |
| Transmitter Power | 1 dBm to 6 dBm |
| Receiver Sensitivity | <-20 Bm |
| Data Rate | 10 Gb / s |
| Power supply | Single 3.3 V |
| Extinction ratio | >3.5 dB |
| Receiver Overload | >-6 dBm |
| Environment | Operating: 32 °F to 158 °F (0 °C to 70 °C)Storage: -40 °F to 185 °F (-40 °C to 85 °C) |
| Weight | 0.06 lb (30 g) |
