Overview
Emissions And Stack SFP transceiver compatible used on a series of switches, routers, servers, network interface card etc, package: SFP+, data rate: 10 G, wavelength: 1528.77 nm to 1563.86 nm, reach: 40 km (24.85 mi), TX EML CWDM, RX PIN, TX Power-1 dBm to 3 dBm, RX. sensitivity of 16 dBm.
Features
- Hot-pluggable
- RoHS Compliant
- Low power dissipation
- Metal enclosure, for lower EMI
- DWDM EML transmitter and PIN receiver
- Compliant with SFP+ MSA with LC connector
- 2 – wire interface with integrated Digital Diagnostic monitoring
- Up to 24.85 mi (40 km) transmission distance over Single Mode Fiber (SMF).
Technical Specifications
| Data Rate | 10 G |
| Reach | 24.85 mi to 49.70 mi (40 km to 80 km) |
| Power Supply Voltage | -0.3 V to +4 V |
| Signal Input Voltage | -0.3 V to +0.3 V |
| Relative Humidity | 5% to 95% |
| Wavelength | 1528.77 nm to 1563.86 nm |
| Temperature | 32 °F to 158 °F (0 °C to 70 °C) |
