Overview
Emissions And Stack tunable SFP + transceivers are designed for use in 1 Gbps to 11.3 Gbps multi-rate 50 GHz / 100 GHz DWDM links with single mode fiber. Compatible with multiple network applications and transmission formats: CPRI, OTN, Fibre Channel, etc. Hot pluggable, and with narrow band tunability, it significantly reduces sparing and configuring costs in optical networks.
Features
- Hot-pluggable SFP + form factor
- Duplex LC connector
- Maximum link length of 49.70 mi (80 km)
- Power dissipation <3 W
- Built-indigital diagnostic functions
Technical Specification
| Data Rate | 1.0 Gbps to 11.3 Gbps |
| Optical output power | -2 dBm to +4 dBm |
| Side – mode Suppression Ratio | 35 dB |
| Power supply | Single 3.3 V |
| Extintion ratio | 8.2 dB |
| Spectral excursion | -11 GHz to + 11 GHz |
| Receive Sensitivity | -21 dBm |
| Receiver wavelength range | 1260 nm to 1600 nm |
