Overview
Emissions And Stack XFP DWDM optical transceiver module is under development now. DWDM stands for Dense Wavelength-Division Multiplexing. It is a technology which multiplexes a number of different “colored” optical signals together. These systems are popular with telecommunications companies because they allow them to expand the capacity of the network without laying more fiber. More recently, smaller ISP’s have been using this equipment as well; they will rent or buy “dark fiber” and by utilizing DWDM they can put more traffic over the same line. Light rend has industry fastest lead time on DWDM 10 G transceivers in different for factors.
Features
- Supports 9.95Gb/s to 11.1Gb/s bit rates
- DWDM 100 Ghz or DWDM 50 Ghz
- Can be used with single fiber DWDM system, dual fiber DWDM system
- Hot-pluggable XFP footprint
- Maximum link length of 49.70 mi (80 km)
- Cooled DWDM EML laser
- Duplex LC connector
- Low Power dissipation
- Built-in digital diagnostic functions, DDMI
- Temperature range 23 °F to 158 °F (-5 °C to 70 °C)
Technical Specifications
| Use | 10 G Ethernet |
| Connector type | Duplex LC |
| Data rate | 10 Gbps |
| Wavelength | DWDM 100 GHz |
| Distance | 24.85 mi (40 KM) or 49.70 mi (80 KM) |
| Working temperature | 32 °F to 158 °F (0 °C to 70 °C) |
