Features
- High-definition core Alignment
- Faster Splicing 5 s
- Heating time 9 s
- Splicing loss SMF 0.01 dB (Typical)
- Fully optimized dual independent ovens
- Touch panel operation with brand-new UI
- Smartphone-like effortless operation
- Long battery life
- IP x 2 water protection
- IP x 5 dust protection
- Work at 3.73 mi (6000 m)
- 92 in (76 cm) drop on 5 faces
- 85 lb. (2.2 kg) with battery
- Faster 5 s splice in SM Quick Mode
- 9 s heat shrink time
- Wide and high-resolution touch panel
- 5 in (12.7 cm) touch screen LCD display
- IPx2 water protection
- IP5x dust protection
- Splice at 122 °F (50 °C)
- Work at 3.73 mi (6000 m)
- Productive
- Programmable
- User selectable clamp operation
Technical specifications
| Fiber | Single mode (G.652 & G.657), Multimode (G.651), DS (G.653), EDF (G.657) |
| Fiber Diameter | Fiber Cladding: 80 μm to 150 μm, Coating: 100 μm to 1,000 μm |
| Fiber Cleave Length | 0.2 in to 0.63 in (5 mm to 16 mm) |
| Splicing Time | Quick Mode: 5 s, Standard and Auto Mode: 7 s |
| Heating Time | 9 s |
| Splice and Heat Cycles | 300 per full charge |
| Fiber View And Magnification | 2 CMOS cameras, 380 x (Zoom: 760 x) |
| Splice Image Capture or Data Storage | 200 images and 10,000 splice data |
| Weight | 4.19 lb (1.9 kg) |
