Technical Specifications
| Alignment Mode | 4 motors core to core alignment |
| Heating Mode | Automatic heating system |
| Fiber Diameter | 80 μm to 150 μm |
| Typical Splicing Time | 6 s |
| Return Loss | > 60 dB |
| Storage Of Splice Result | 10000 results, 20 parameter per result |
| Electrode Life | 3600 times |
| Tension Test | 2 N |
| Power Supply | 100 V to 240 V 50 Hz or 60 Hz |
| Windproof Performance | max wind velocity of 15m per s |
| Temperature | -4 ℉ to 122 ℉ (-20 ℃ to 50 ℃) |
| Size | 5.12 in x 5.12 in x 4.72 in (13 cm x 13 cm x 12 cm) |
| Weight | 5.35 lbs (2.43 kg) |
