Features
- 6 motors
- Accurate real core to core alignment
- 5 in (12.7 cm) high resolution color touch screen
- Identify fiber types (SM or MM) automatically
- 6 s splicing
- 18 s heating
- Automatic & real-time ARC calibration
- Industrial quad-core CPU with 30% power saving
- Real-time heating temperature monitoring
- Anti-shock
- Anti-vibration
- Dustproof & waterproof
Technical specifications
| Alignment method | 6 motors core to core alignment |
| Applicable fiber | SM (G.652), MM (G.651), DS (G.653), NZDS (G.655), BIF (G.657) |
| Cladding diameter | 80 μm to 150 μm |
| Coating diameter | 160 μm to 3000 μm |
| Cleaved length | 0.197 in to 0.629 in (5 mm to 16 mm) (coating diameter < 250 um) 0.629 in (16 mm) (coating diameter:250 um to 3000 um) |
| Typical splice loss | SM: 0.02 dB; MM: 0.01 dB; DS or NZDS or BIF: 0.04 dB |
| Return loss | > 60dB |
| Splicing program | 40 groups |
| Operation mode | Manual and Automatic |
| Auto-heating | Available |
| Typical splice time | 6 s |
| Typical heating time | 18 s for 2.36 in (60 mm) and 1.57 in (40 mm) shrinkable sleeves |
| Fiber magnification | 250 x (X or Y view), 125 x (X and Y view) |
| Viewing display | Dual high sensitivity camera, 5 in (12.7 cm) 800 x 480 LCD Touch Screen Monitor |
| Data storage | 4000 groups data records |
| Loss evaluation | Available |
| Tension test | 1.8 N to 2.25 N |
| Interface | GUI menu interface, easy for operation |
| Battery capacity | 5200 mAh Li-battery, 250 cycles splicing and heating |
| Power supply | Adaptor, input: AC 100 V to 240 V (50 Hz to 60 Hz), output: DC 11 V to 13.5 V |
| Electrode life | More than 4000 ARC discharges, easy to replace |
| Terminals | USB 2.0 port, for software upgrading, records exporting |
| Operating | Altitude: 0 mi to 3.011 mi (0 m to 5000 m), Humidity:0 % to 95 %, Temperature: 14 ° F to 122 ° F (-10 ° C to +50 ℃); Wind: max 15 m/s |
| Dimension | 6.14 in x 5.55 in x 6.14 in (156 mm × 141 mm × 156 mm) |
| Weight | 5.4 lb. (2.45kg) (including battery) |
