Features
- Intelligent
- High precision
- Fully automatic alignment
- 9 s welding
- 15 s heating
- Simple and efficient operation
- 5 in (12.7 cm) TFT color LCD display
- Flip operation of screen is available
- 4 motors
- LED lighting available
- 6400 mAh large capacity Li battery
- 8 V power supply
- 5 hours charging time
- > 200 times charging time
Technical specifications
| Network | Wireless Lan, Bluetooth, Wired LAN, ONVIF, None, None, SDK, TCP, Ip, POE, GPRS, Wi-Fi, 4g, GSM, 3G, Wiegand |
| Alignment mode | Cord to Cord |
| Use | FTTH FTTB FTTX Network |
| Language | Multi-Language |
| Material | Metal and plastic |
| Focus mode | Six motors Auto focus |
| Boot time | 1 s |
| Return loss | Better than 60 dB |
| Battery | 6400 mAh |
| Applicable Fibers | SM (G.652 & G.657), MM (G.651), DS (G.657), NZDS (G.655) |
| Splice Loss | 0.025 dB (SM), 0.01 dB (MM), 0.04 dB (DS or NZDS) |
| Control technology | Real-time control and calibration of fusion ARC |
| Fiber Cleave Length | Coating less than 250 µm: 0.315 in to 0.63 in (8 mm to 16 mm) Coating less than 250 µm to1000 µm: 0.63 in (16 mm) |
| Fiber holder | SM, MM, bare fiber, pigtail, rubber-insulated, multi fiber cable |
