Technical Specifications
| Pulse Width | (SM 1310/1550NM) 5ns 10ns 20ns 50ns 100ns 500ns 1μs 2μs 5μs 10μs: (MM 850/1300NM) 5ns，10ns，20ns，50ns，100ns，500ns， 1us |
| Distance Range | (SM 1310/1550NM) Dead zone test, 1.3km, 2.5km, 5.0km, 10km, 20 km, 40 km, 80 km, 120 km, (MM 850/1300NM):100 m, 400 m, 1.3 km, 2.5km, 5km, 10km, 20km, 40km, 80km |
| Sampling Resolution | Minimum 0.05m |
| Sampling Point | 1,28,000 |
| Linearity | ≤0.05dB/dB |
| Loss Threshold | 0.01 dB |
| Loss Resolution | 0.001 dB |
| Distance Resolution | 0.01 m |
| Distance Accuracy | ±（1m+measuring distance×3×10 +sampling resolution） |
| Data Storage | 80000 groups of curves |
| VFL | 10 mW, CW/2Hz |
| Interface | 3 USB ports (Type A×2， Type B×1） |
| Display | 5.6-inch TFT-LCD, Touching screen |
| Battery | 7.4V/4.4Ah lithium battery supports 8 hours continuous working |
| Working Conditions | Working Temp：14°F to 122°F (-10℃ to +50℃); Storage Temp: -4°F to 158°F (-20℃ to +70℃); Humidity ：≤95%（non-dew） |
| Dimensions | 9.96 in × 6.61 in × 28.94 in (25.3 cm × 16.8 cm × 73.5 cm) |
| Weight | 3.31 lbs (1.5 kg incl battery) |
