Technical Specifications
| Waveforms | Sine, square, pulse, ramp, noise, DC, arbitrary |
| Power supply | 100 V AC to 240 V AC, 50 Hz or 60 Hz |
| Working Temperature | 32 °F to 104 °F (0 ℃ to 40 ℃) |
| Channel | 2 |
| Max frequency | 60 MHz |
| Sampling rate | 200 MS/s |
| Vertical resolution | 14 bits |
| Sweep modes | Logarithmic, linear |
| Resolution | 1 μHz |
| Accuracy | Within 90 days ± 50 ppm |
| Accuracy | Within 1 year ± 100 ppm |
| Accuracy | 64.4°F to 82.4°F (18 ℃ to 28 ℃) |
| Impedance | 50 ohms or High Z |
| Amplitude range | 1 mVpp to 10 Vpp (50 ohms), 2 mVpp to 20 Vpp (high Z) |
| DC offset range (AC+DC) | ±5 V (50 ohms), ±10 V (high Z) |
| Amplitude resolution | 1 mV |
| Power | 100 to 240 V AC, 50 Hz or 60 Hz |
| Display | 4.3 in (10.92 cm) TFT LCD (480 × 272) |
| Product colour | White and grey |
| Standard accessories | USB interface cable, power cord, BNC cable with alligator clips |
| Standard quantity per carton | 4 pcs |
| Product size | 6.77 in x 3.54 in x 2.67 in (172 mm x 90 mm x 68 mm) |
| Product net weight | 0.07 lb (330 g) |
