Overview
Emissions And Stack inductance tester data logger adopts high-performance 32-bit ARM microprocessor control. It has ultra-low power consumption and density SMD assembly technology, colour TFT-LCD display with keyboard, touch screen double control. This device has a Li-battery, USB communication and English operation. The frequency ranges from 100 Hz to 100 kHz with internal resistance of 100 Ω and 0.6 Vrms test signal level with 0.2 % accuracy. This device is also CE certified.
Technical Specifications
| Parameters | L, C, R, Z Auto |
| Sub Parameters | OFF, AUTO, D, Q, θr, θd, X, ESR |
| Accuracy | 0.20 % |
| Frequency | 100 Hz to 100 kHz |
| Resistance | 100 Ω |
| Range | Auto, Manual |
| Max Display | Principal parameter: 49999 Sub parameter: 49999 |
| Signal Level | 0.6 Vrms, accuracy ±10 % |
| Speed | 1.5 times per second to 4 times per second |
| Comparator | 1set, main parameter compares, beep |
| Power Supply | Input:100 V to 240 V and 50Hz to 60Hz 0.35A Output :9 V 1 A DC |
| Battery | 8.4 V, Li, 1400 mAh rechargeable |
| Charging Time | Max single continuous: 200 Min |
| Working Time | Highlight 30 % ≥ 14 H, highlight50 % ≥ 11 H, Highlight 100 % ≥ H |
| Accessories | Kelvin test clip, DC adapter, Li battery, USB communications cable, data acquisition software |
| Size | 3.5 in x 7.67 in x 1.39 in (90 mm x 195 mm x 35.5 mm) |
| Weight | 0.88 lb (400 g) |
