| Bandwidth |
60 MHz |
| Sample Rate (Real Time) |
1 GS/s |
| Horizontal Scale (S/div) |
2 ns/div to 100 s/div, step by 1 to 2 to 5 |
| Rise Time (at input, typical) |
<=5.8 ns |
| Channels |
Dual + External Trigger |
| Horizontal Scale |
(s/div) 2 ns/div to 100 ns/div, step by 1 to 2 to 5 |
| DC Accuracy (Average) |
Average>16: ± (3% reading + 0.05 div) for ΔV |
| Vertical Sensitivity |
2 mV/div to 10 V/div |
| DC Gain Accuracy |
±3% |
| Vertical Resolution (A or D) |
8 bits (2 channels simultaneously |
| Interpolation |
Sin (x)/x |
| Max Input Voltage |
400 V (DC + AC, PK to PK) |
| Probe Attenuation Factor |
1X, 10X, 100X, 1000X |
| Trigger Mode |
Edge, Video, Alternate, Pulse and Slope |
| Acquisition Mode |
Normal, Peak Detect and Average |
| Record Length |
2 M Points |
| Waveform Storage |
4 Waveforms |
| Automatic Measurement |
Vpp, Vavg, Vrms, Freq, Period, Vmax, Vmin, Vtop, Vbase, Vamp, Overshoot, Preshoot, Rise Time, Fall Time, Delay A to B, +width, -width, +Duty, -Duty |
| Waveform Math |
+, -, x, ÷, invert, FFT |
| Power Supply |
100 V to 240 V AC, 50 Hz or 60 Hz, CATII |
| Bandwidth |
60 MHz, 100 MHz, 200 MHz |
| Phase Difference |
±3 degrees |
| Communication Interface |
USB host, VGA (optional), and USB device |
| Fuse |
1 A, T class, 250 V |
| Battery |
7.4 V, 800 mAh (Optional) |
| Dimension |
14.57 in x 7.09 in x 4.72 in (370 mm x 180 mm x 120 mm) |
| Weight |
4.85 lb (2.20 kg) |
