Features
- Handhold, small, light
- 8 s splicing time, 18 tube heating time
- 5800 mAh and pluggable li-battery, typical 240 cycles
- USB interface for software updating and data records downloading
Technical Specifications
| Applicable Fiber | SM, MM, DS, NZDS |
| Diameter Of Cladding | 0.003 in to 0.005 in (80 μm to 150 μm) |
| Diameter Of Coating | 0.006 in to 0.03 in (160 μm to 900 μm) |
| Typical Splice Loss | SM: 0.02 dB, MM: 0.01 dB, DS: 0.04 dB, NZDS: 0.04 dB |
| Return Loss | Greater than 60 dB |
| Splicing Program | 40 groups |
| Operate Mode | Automatic or manual |
| Auto-heating | Available |
| Typical Splicing Time | 7 s |
| Typical Heating Time | 26 s |
| Fiber Magnification | 250 X (X or Y view), 125 X (X and Y view) |
| Display Screen | 4.3 in (10.92 cm) color LCD monitor, touch screen |
| Records Storage | 4000 results |
| Loss Evaluation | Available |
| Tension Test | 1.8 N to 2.2 N |
| Interface | GUI menu interface, easy for operation |
| Battery | 5200 mAh Li-battery, typical 250 cycles splicing and heating |
| Power Supply | Adapter, input: AC 100 V to 240 V (50 Hz or 60 Hz), output: 11 V to 13.5 V |
| Electrodes Life | More than 4000 ARC discharges, can be replaced conveniently |
| Terminal | USB 2.0 port, for software upgrading and records exporting |
| Operating Conditions | Altitude: 0 ft to 3.1 mi (0 m to 5000 m),
Humidity: 0 % to 95 %, Temperature: 14 °F to 122 °F (-10 ℃ to 50 ℃), Wind speed: max 15 m/s |
| Dimension (L X W X H) | 5.90 in x 4.72 in x 5.31 in (150 mm x 120 mm x 135 mm) |
| Weight | 3.85 lb (1.65 kg) (including battery) |
