Technical specifications
| Fiber Alignment | PAS core alignment |
| Applicable Fibers | Single or SMF (G.652 or 657), MMF (G.651), DSF (G.653), NZDSF (G.655), BI (G.657) |
| Cladding Diameter | 80 μm to 150 μm |
| Sheath Diameter | 100 μm to 1000 μm |
| Cleave Length | 0.315 in to 0.63 in (8 mm to 16 mm) |
| Splice Mode | Total 100 modes, supports self-defined mode and parameters |
| Typical Splice Time | 6 s SM FAST |
| Typical Splice Loss | 0.02 dB (SM), 0.01 dB (MM), 0.04 dB (DSF) ,0.04 dB (NZDS) and 0.02 dB (BI) |
| Return Loss | >> 60 dB |
| Heating Mode | Max. 20 |
| Heating Time | 16 s |
| Applicable Protection Sleeve | 0.93 in to 2.36 in (10 mm to 60 mm) |
| Splice Result Storage | Last 20,000 splices |
| Splice Image Storage | Max 800 |
| Viewing Methods | 2 axis CMOS camera with 4.3 in (10.92 cm) HD color capacitive touchscreen |
| Magnification | Supports X or Y or both X and Y simultaneously, maximum up to 760 x magnification |
| Port | MicroSD and USB port for software upgrade or data management |
| Electrode Life | Typical 5000 splices |
| Battery Compacity | 4000 mAh battery, more than 220 times splicing and heating; Standard charging time 3 hours (up to 80% electric quantity in 2 hours) |
| Power Supply | AC 100 V to 240 V, 50 Hz or 60 Hz |
| Tension Test | 2 N |
| Operating Condition | Altitude: 0 ft (0 m) to 3.11 mi (5000 m) above sea levelWind: 15m/sec |
| Storage Condition | Temperature: 14 °F to 122 °F (- 10 °C to +50 °C)Humidity: 0 % to 95 %
Temperature: 14 °F to 176 ° F (-10 ° C to 80 ° C) Battery temperature: 14 °F to 104 ° F (-10 ° C to 40 ° C) |
| GPS (option) | GPS positioning and tracking system through inbuilt SIM card |
| Size (W X D X H) | 5.26 in x 5.67 in x 5.26 in (133 mm x 144 mm x 133 mm) |
| Weight | 3.31 lb. (1.5 kg)3.97 lb. (1.8 kg) including battery |
