| Fibre alignment |
Core or cladding alignment 1 Manual alignment |
| Splicing time |
5 S |
| Heating time 18S |
15 S |
| Heating mode |
Automatic heating (Preheating) |
| Focus mode |
Six motors Auto focus |
| Applicable Fibres |
SM (G 652 & G.657), MM (G.651), DS (G.657), NZDS (G.655) |
| Splice Loss |
0.025 dB (SM), 0.01 dB (MM) 0.04 dB (DSINZDS) |
| Control technology |
Real-time control and calibration of fusion ARC |
| Return loss |
Better than 60 dB |
| Fibre diameter |
Cladding Diameter: 80 µm to 150 µm Coating Diameter: 100 µm to 1000 µm |
| Fibre Cleave Length |
Coating less than 250 µm; 0.3 in to 0.62 in (8 mm to 16mm) Coating less than 250 µm to 1000 µm: 0.63 in (16 mm) |
| Built-in lighting |
Easy for night operation |
| Tension Test |
Standard 2 N |
| Fibre holders |
3 in 1 fibre holder, SM, MM, bare flyer, pigtail, rubber _insulated, multi fibre cable |
| Magnification |
300 for X or Y view,150 for X or Y view |
| Screen |
5 in (12.7 cm) TFT colour display |
| Splicing Mode |
Normal 1 high precision splicing |
| Splicing record storage |
Synchronize to the phone, the server to cloud storage unlimited |
| Built-in battery |
7800 mA high-capacity lithium battery, charging time s 3.5 hrs, continuous splicing, and heating about 260 times |
| Power supply |
Input AC100 to 240 V 50 Hz or 60 HZ, output DC 13.5 V1 4 A, the current power mode can be identified, real-time detection of battery power |
| Operating Conditions |
Temperature: 5 °F to 122 °F (-15 °C to +50 °C), humidity: ＜95 % RH (no condensation). Resist max. wind speed: S 15 m/s |
| Shrinkable tube |
2.3 in, 1.5 in (60 mm, 40 mm) |
| Visual Fault Locator |
Power: 15 mW, 2 Hz flashing And Constantly Bright Mode |
| Weight |
4.58 lb (2.08 kg) |
