| Applicable Fiber |
SM (ITU-T G.652), MM (ITU-T G.651,) DS (ITU-T G.653), NZDS (ITU-T G.655) |
| Diameter Of Cladding |
0.0031 in to 0.0059 in (80 μm to 150 μm) |
| Diameter Of Coating |
0.0062 in to 0.035 in (160 μm to 900 μm) |
| Typical Splice Loss |
SM: 0.02 dB, MM: 0.01 dB, DS: 0.04 dB, NZDS: 0.04 dB |
| Return Loss |
>60 dB |
| Fiber Cleaves Length |
0.19 in to 0.63 in (5 mm to 16 mm) (coating diameter< 0.0098 in (250 um)), 0.62 in (16 mm) (coating diameter: 0.0098 in to 0.039 in (250 um to 1000 um)) |
| Splicing Program |
40 groups |
| Operate Mode |
Automatic or Manual |
| Auto-heating |
Available |
| Typical Splicing Time |
7 seconds |
| Typical Heating Time |
26 seconds |
| Fiber Magnification |
250X (X or Y view), 125X (X and Y view) |
| Display Screen |
4.3 in (109.22 mm) color LCD monitor, Touch screen |
| Records Storage |
4000 results |
| Loss Evaluation |
Available |
| Tension Test |
1.8 N to 2.2 N |
| Interface |
GUI menu interface, easy for operation |
| Battery |
5200 mAh Li-battery, typical 250 cycles splicing and heating |
| Power Supply |
Adapter, input: AC 100 V to 240 V (50 Hz), output: 11 V to 13.5 V |
| Electrodes Life |
More than 4000 ARC discharges, can be replaced conveniently |
| Terminal |
USB 2.0 port, for software upgrading and records exporting |
| Operating Conditions |
Altitude: 0 mi to 3.10 mi (0 m to 5 km), Humidity:0 % to 95 %, Temperature: (10 ֯ F to 122 ֯ F) -10 ℃ to +50 ℃, Wind speed: Max 19.21 ft (15 m) per sec |
| Dimension |
5.90 in x 4.72 in x 5.31 in (150 mm(L) x 120 mm(W) x 135 mm(H)) |
| Weight |
3.63 lbs (1.65 kg) (including battery) |
