Features
- Measuring frequency up to 100 kHz, continuous adjustable frequency of 1 Hz step by step
- Test level 10 mv to 2000 mv, 1 Hz continuous adjustable
- Support dc resistance (DCR), electrolytic capacitor measurement
- The internal bias voltage output 0 mv to 1500 mv
- 5″ TFT display, five shows
- Communications: USB Device, RS232, Handle
- Data record function (maximum, minimum, average)
- Support SCPI communication protocol
- Provide the system Settings, can according to need to configure the Chinese or English, buzzer, screen brightness, etc
- Basic measurement accuracy of 0.1 %
- Manual and automatic range
- With open circuit and short circuit calibration function
- Comparator separation (5), alarm function
Technical Specification
| Power Voltage | 220 V or 50 Hz or 110 V or 50 Hz |
| Power Consumption | < 10 W |
| Basic Accuracy | 0.1 % |
| Internal Bias | 0 mV to 1500 mV adjustable, at a step of 1 mV |
| Testing Level | 0.1 V to 2 V, continously adjustable, 1 mV step |
| Measurement Range | L: 0.001 µH to 9999 HC: 0.001 pF to 99.999 mF
R: 0.0001 Ω to 99.99 m Ω |
| Signal Source Output | 30 Ω, 100 Ω |
| Display | 3.5 in TFT LCD |
| Resolution | 480 x 320 |
| Interaces | RS232, USB Device, Handler |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
